    Features

    • Designed for long life at full power
    • Excellent dynamic response to load changes
    • Protected against all overload and short circuit conditions
    • EMC surpasses CE requirements:low emission & high immunity
    • Low audible noise: fan is
    • Units Voltage range Current range temperature controlled
    150W to 6kW; Bench, Eurocassette & 19" Rack Mounting; Output Voltage & Current Programmable by Analogue Voltage Input or RS232, IEEE488, Ethernet, CANopen Fieldbus or Profibus Interfaces; Series or Parallel Operation possible; Options include: High Speed Programming, 2-Quadrant Power Sink, Increased Output Power, Sequencer/Waveform Generator

    Inquiry Info. PDF

  • ES150 Series

    Features

    • Very low out put ripple and spikes
    • EMC sur passes CE requirements:low emission & high immunity
    • High programming speed
    • Excellent dynamic response to load changes
    • Protected against all over load and short circuit conditions
    • Designed for a long life at full power
    150W; Output Voltages up to 300VDC; Output Currents up to 10ADC; Universal Single Phase AC Input Voltage; Output Voltage & Current Programmable from 0-100%; Parallel & Series Operation with Voltage & Current Sharing Options: Increased Output Power, High Voltage Isolation, Secured Output Voltage & Current Settings, Sequencer, Rear Output Terminals, 19" Rack Mounting Adapter Software Control & Interfaces: 0-5V Analogue, RS232, Ethernet (incl. sequencer), PROFIBUS, CANBUS, IEEE488, ISO AMP CARD (isolated analogue)

    Inquiry Info. PDF

  • ES300 Series

    Features

    • Very low out put ripple and spikes
    • EMC surpasses CE requirements: low emissions & high immunity
    • High programming speed
    • Excellent dynamic response to load changes
    • Protected against all over load and short circuit conditions
    • Designed for a long life at full power
    300W; 0-30V 0-10A DC Output; Universal Single Phase AC Input; Output Voltage & Current Programmable from 0-100%; Parallel & Series Operation with Voltage & Current Sharing Options: Increased Output Power, High Voltage Isolation, Sequencer, Rear Output Terminals, 19" Rack Mounting Adapter Software Control & Interfaces: 0-5V Analogue, RS232, Ethernet (incl. sequencer), PROFIBUS, CANBUS, IEEE488, ISO AMP CARD (isolated analogue)

    Inquiry Info. PDF

  • SM800 Series

    Features

    • Designed for long life at full power
    • Excellent dynamic response to load changes
    • Protected against all over load and short circuit conditions
    • EMC surpasses CE requirements:low emission & high immunity
    • Low au dible noise: fans are temperature controlled
    • Available options: High Speed Programming, Interfaces, Extra Isolation,
    • Sequencer, Digital Encoders, Power Sink etc.
    800W; Output Voltages up to 400VDC; Output Currents up to 80ADC; Single Phase AC Input Voltage; Active PFC; Output Voltages & Currents Programmable from 0-100%; Series & Parallel Operation with Voltage & Current Sharing Options: Increased Output Power, High Speed Programming, 2-Quadrant Power Sink, Digital Voltage & Current Settings, High Voltage Isolation, Secured Voltage & Current Settings, Sequencer, Front Panel Outputs, 19" Rack Mounting Adapter Software Control & Interfaces: 0-5VDC Analogue, Ethernet (incl. sequencer), RS232, IEEE488, PROFIBUS, CANBUS, ISO AMP CARD (isolated analogue)

    Inquiry Info. PDF

  • SM1500 Series

    Features

    • cTUVus safety approval
    • Designed for long life at full power
    • Excellent dynamic response to load changes
    • Protected against all over load and short circuit conditions
    • EMC surpasses CE requirements:low emission & high immunity
    • Low audible noise: fans are temperature controlled
    • Avail able options: High Speed Programming, Interfaces, Extra Isolation, Sequencer, Digital Encoders, Power Sink etc.
    1500W; Output Voltages up to 400VDC; Output Currents up to 100ADC; Single Phase AC Input Voltage; Active PFC; Output Voltage & Current Programmable from 0-100%; Series & Parallel Operation with Voltage & Current Sharing Options: Increased Output Power, High Speed Programming, 2-Quadrant Power Sink, Sequencer, High Voltage Isolation, Secured Voltage & Current Settings, Digital Voltage & Current Settings Software Control & Interfaces: 0-5VDC Analogue, Ethernet (incl. sequencer), RS232, IEEE488, PROFIBUS, CANBUS, ISO AMP CARD (isolated analogue)

    Inquiry Info. PDF

  • SM3300 Series

    Features

    • Designed for long life at full power
    • Excellent dynamic response to load changes
    • Protected against all over load and short circuit conditions
    • EMC surpasses CE requirements: low emission & high immunity
    • Low audible noise: fan is temperature controlled
    • Available Options : Software control and Interfaces,
    • High Speed Programming, Two-Quad rant Out put - PowerSink
    3300W; Output Voltages up to 660VDC; Output Currents up to 220ADC; Single or 3 Phase AC Input Voltage; Active PFC; Output Voltage & Current Programmable from 0-100%; Plug and Play Interfaces; Digital Voltage & Current Settings; Ethernet Controller; Sequencer; High Voltage Isolation; USB Input Options: High Speed Programming; 2-Quadrant Power Sink Software Control & Interfaces: 0-5V Analogue, Ethernet, RS232, RS485, RS422, USB

    Inquiry Info. PDF

  • SM6000 Series

    Features

    • cTUVus safety approval
    • Designed for long life at full power
    • Excellent dynamic response to load changes
    • Protected against all over load and short circuit conditions
    • EMC surpasses CE requirements:low emission & high immunity
    • Low audible noise: temperature controlled fans
    • Available options: an a log & digital Interfaces, High Speed Programming,
    • Digital Encoders, Sequencer, Power Sink etc.
    6000W; Output Voltages up to 600VDC; Output Currents up to 400ADC; 3 Phase AC Input; Active PFC; Output Voltage & Current Programmable from 0-100%; Parallel & Series Operation with Voltage & Current Sharing Options: Increased Output Power; High Speed Programming; High Voltage Isolation; Sequencer; Secured Voltage & Current Settings; 2-Quadrant Power Sink; Digital Voltage & Current Setting; High AC Voltage Input Software Control & Interfaces: 0-5V Analogue; Ethernet (incl. sequencer); PROFIBUS; CANBUS; RS232; IEEE488; ISO AMP CARD (isolated analogue)

    Inquiry Info. PDF

  • SM15K Series

    Features

    • Bi-Directional power supply, standard 15kW Source & Sink
    • Flexible output with constant power characteristic
    • Power Regeneration Technology: sink power is not dissipated but fed back into the grid
    • Designed for long life at continuous full power
    • Excellent dynamic response to load changes, digital controlled with the possibility to adapt to the type of load
    • Very low heat dissipation, efficiency 95% or more
    • Protected against all overload and short circuit conditions

    Inquiry Info. PDF

Total of 8 results
