EPL225 Series

Features

• 225W fan cooled 150W convection cooled
• 101.6 x 50.8mm (4” x 2”) footprint 32.3mm profile
• Regulated single outputs 12V to 48VDC
• Input range 85 to 264VAC
• High efficiency – up to 95%
• Medical (2 x MOPP) & ITE approvals
• 4.0kVAC input to output isolation
• Class I & class II applications
• <0.5W no load input power
• 12VDC 0.5A fan supply
• -20°C to +70°C operating temperature
• Full load to +50°C
• 3 year warranty
