• High Power Switch Mode Power Supplies up to 22kW

  • CPS-EP3000

    Features

    • Optional LAN interface plug & play
    • 3D Heat Dissipation
    • CSB Current Share Bus paralleling 7 units
    • Inhibit for safe interlocking
    • Remote Shutdown
    • Sense mode
    • Current Monitoring 0-5V
    • Power Good Relay DC-ok
    • Precise dynamics on load change
    • Series & parallel operation up to 100kW
    • EMC conducted class B, radiated class A
    • Efficiency 92-94%
    • PFC Powerfactor 0,99
    • Variable controlled fans from Papst
    • Long lifetime under hard operation
    • Solid 2U and 3U subframes available
    CPS-EP3000 Series 3000 Watts. 19” 2U or 3U rack mounting. 184-264VAC or 250-375VDC Input. Seven output model versions from 12V DC to 220V DC. Wide output adjustability.

    Inquiry Info. PDF

  • CPS-EX2000

    Features

    • Optional LAN interface plug & play
    • 3D Heat Dissipation
    • Real time I/V programming
    • Real time I/V-monitoring
    • Reference voltage f. autonomous programming
    • CSB Current Share Bus paralleling 7 units
    • Inhibit for safe interlocking
    • Remote Shutdown
    • Sense mode
    • Power Good Relay DC-ok
    • Precise dynamics on load change
    • Series & parallel operation up to 100kW
    • EMC conducted class B, radiated class A
    • Efficiency 92-94%
    • PFC Powerfactor 0,99
    • Variable controlled fans from Papst
    • Long lifetime under hard operation
    • Solid 2U and 3U subframes available
    CPS-EX2000 Series 2000 Watts. 19” 2U or 3U rack mounting. 184-264VAC or 250-375VDC Input. Five output voltage versions available, programmable for voltage and current from 24-30VDC 42-84A to 90-150VDC 9.1-18.2A.

    Inquiry Info. PDF

  • CPS-EX3000

    Features

    • Optional LAN interface plug & play
    • 3D Heat Dissipation
    • Real time I/V programming
    • Real time I/V-monitoring
    • Reference voltage f. autonomous programming
    • CSB Current Share Bus paralleling 7 units
    • Inhibit for safe interlocking
    • Remote Shutdown
    • Sense mode
    • Power Good Relay DC-ok
    • Precise dynamics on load change
    • Series & parallel operation up to 100kW
    • EMC conducted class B, radiated class A
    • Efficiency 92-94%
    • PFC Powerfactor 0,99
    • Variable controlled fans from Papst
    • Long lifetime under hard operation
    • Solid 2U and 3U subframes available
    CPS-EX3000 Series 3000 Watts. 19” 2U or 3U rack mounting. 184-264VAC or 250-375VDC Input. Seven output voltage versions available, programmable for voltage and current from 2-15VDC 100-200A to 200-300VDC 6.8-13.6A.

    Inquiry Info. PDF

  • CPS-i2000

    Features

    • Optional LAN interface plug & play
    • 3D Heat Dissipation
    • Real time I/V programming
    • Real time I/V-monitoring
    • Reference voltage f. autonomous programming
    • CSB Current Share Bus paralleling 7 units
    • Inhibit for safe interlocking & Remote Shutdown
    • Remote Shutdown
    • Power Good Relay AC-ok and DC-ok
    • Precise dynamics on load change
    • Series & parallel operation up to 100kW
    • EMC conducted class B, radiated class A
    • Efficiency 92-94%
    • PFC Powerfactor 0,99
    • Variable controlled fans from Papst
    • Long lifetime under hard operation
    • Fast down programming option PS
    • Solid 2U and 3U subframes available
    CPS-i2000 Series 2000 Watts. 19” 2U or 3U rack mounting. 184-264VAC or 250-375VDC Input. Five output voltage versions available, fully programmable for voltage and current from 0-18VDC 0-165A to 0-150VDC 0-20A.

    Inquiry Info. PDF

  • CPS-i3000

    Features

    • Optional LAN interface plug & play
    • 3D Heat Dissipation
    • Real time I/V programming
    • Real time I/V-monitoring
    • Reference voltage f. autonomous programming
    • CSB Current Share Bus paralleling 7 units
    • Inhibit for safe interlocking & Remote Shutdown
    • Remote Shutdown
    • Power Good Relay AC-ok and DC-ok
    • Precise dynamics on load change
    • Series & parallel operation up to 100kW
    • EMC conducted class B, radiated class A
    • Efficiency 92-94%
    • PFC Powerfactor 0,99
    • Variable controlled fans from Papst
    • Long lifetime under hard operation
    • Fast down programming option PS
    • Solid 2U and 3U subframes available
    CPS-i3000 Series 3000 Watts. 19” 2U or 3U rack mounting. 184-264VAC or 250-375VDC Input. Six output voltage versions available, fully programmable for voltage and current from 0-18VDC 0-185A to 0-300VDC 0-12.5A.

    Inquiry Info. PDF

  • NanofleX

    Features

    • Configurable power supply
    • Low profile for 1U applications
    • Medical and ITE approvals
    • Power from 850W at low line to 1200W at high line
    • Output voltages from 3V3 to 60V
    • Module power up to 300W
    • Parallel options for increased versatility
    • PMBus digital interface
    • Graphical user interface (GUI)
    • Optional reverse air fans with no load derating
    • SEMI F47 compliant
    • 3 year warranty
    NanoFlex Series 850-1200Watts. Metal Fan Cooled Enclosure. 90-264VAC Input. Fully configurable modular DC outputs from 3.3V to 60V at up to 40A per module and up to 4 outputs. PMBus digital interface.

    Inquiry Info. PDF

  • FleXPower

    Features

    • 400W to 1.5kW low line 600W to 2.5kW high line fan cooled
    • Configurable for fast time to market
    • 10/12/14/20 slot models
    • Output modules 3V3 to 60VDC
    • Module power up to 750W
    • Input range 85 to 264VAC
    • Flexible series & parallel capability
    • ITE & industrial or medical (2 x MOPP) versions
    • SEMI F47 compliant
    • Fan speed control
    • -20°C to +70°C operating temperature
    • 3 year warranty
    FleXPower Series 400-2500 Watts. Metal Fan Cooled Enclosure. 85-264VAC Input. Fully configurable modular power supply. DC outputs from 3.3V to 60V at up to 60A per module and up to 7 outputs. Series and parallel configuration.

    Inquiry Info. PDF

  • FLXPro

    Features

    • Up to 23.2W/in³ power density
    • Power from 1kW low line to 1.3kW high line
    • Full power up to +50°C
    • Efficiency up to 93%
    • 2 x MOPP isolation for medical applications
    • 4 selectable outputs from 9VDC to 66VDC
    • Wide output adjustment range
    • Fully digital architecture incorporating iPSU Intelligent Power technology
    • Intuitive UI for configuration, monitoring and control
    • Intelligent configurable fan speed
    • Medical and ITE approvals
    • 3 year warranty
    FLXPro Series 1300 Watts. Metal Fan Cooled Enclosure. 85-264VAC Input. Fully configurable modular DC outputs from 9V to 66V at up to 22A per module and up to 4 outputs. Series and parallel configuration.

    Inquiry Info. PDF

  • XTL15

    Features

    • Configurable for fast time to market
    • Flexible series and parallel capability
    • EN62368-1 and UL62368 safety approvals
    • 3 phase input 180 to 264VAC
    • 1-14 outputs
    • Variable speed fan (optional)
    • Fully featured signals and controls
    • SEMI F47 compliant
    • -20°C to +70°C operating temperature
    • 3 year warranty
    FleXPower XTL15 Series 1500 Watts. Metal Fan Cooled Enclosure. 3 Phase 180-264VAC input. Fully configurable modular DC outputs from 3.3V to 60VDC at up to 60A per module and up to 14 outputs.

    Inquiry Info. PDF

  • XT16

    Features

    • 3 phase input
    • 342 to 528VAC input
    • Configurable for fast time to market
    • SEMI F47 compliant
    • Flexible series and parallel capability
    • -20°C operation
    • Fan speed control
    • 3 year warranty
    FleXPower XT16 Series 1600 Watts. Metal Fan Cooled Enclosure. 3 Phase 342-548VAC input. Fully configurable modular DC outputs from 3.3V to 60VDC at up to 60A per module and up to 14 outputs.

    Inquiry Info. PDF

Total of 30 results
